Services & Rig Packages

Services

Evertson International offers a variety of drilling, completion, and workover services in Venezuela.  From simple pump changes and completions to drilling laterals, Evertson’s rig fleet and experienced personnel are ready to help you meet your well creation and service need.

Rig Packages

Since beginning Venezuelan operations with 2 workover rigs, Evertson has added 4 additional workover rigs and 1 drilling rig to complete its current fleet of 7 rigs. Each Evertson rig is equipped with an extensive equipment package, including mud pumps,  electric generators, forklifts, light towers, tanks, pumps and other petroleum production tools.

In 2015, Evertson began a program of fleet modernization and expansion, which has resulted in improvements to existing rig packages and the addition of new rigs. Evertson plans to bring new workover rigs to Venezuela each year over the next 5 years.  Currently, Evertson’s newest rig package, Rig-10, a 500HP workover rig, was deployed in Q1 2019.

Equipment Specifications Evertson #3 – 500HP Workover

LOCATION: Faja Region, Venezuela
RIG OWNER:
Evertson International
RIG NAME:
 Evertson-03
YEAR BUILT / SERIAL NUMBER: 1974 -REBUILT IN 2015 / S/N:
310
CONDITION / STATUS:
Under Contract/ Active
RIG TYPE:
Land (Workover)

RIG CLASSIFICATION: Self-Propelled
CURRENT FIELD / OPERATOR:
Junin Division/ Petrocedeño
DATE OF LAST OVERHAUL:
August 2016
DATE OF NEXT OVERHAUL:
 August 2021

Motor: Detroit Diesel Series 60

Capacity (HP):  500 HP
Transmission: Allison 4500 OFS
Diameter (inches): 11″
Brake Type: Hydraulic

Model/Type: Watson Hopper GXXTA 102′
Capacity (lbs): 260,000
Max Depth (feet): 10,000

Bore Diameter: 11″

Pressure (PSI): 3,000 PSI

Pressure (PSI): 5,000 PSI

Tubing Tong: Clincher 5.5″ x 6.25″ (12,000 ft-lbs)

Rod Tongs: (1) Hillman Kelley Model 500-C (4,500 ft-lbs); (1) Oil Country  Model M50 (2,050 ft-lbs)

Quantity: 1
Model: GD TGH-A
Type: Triplex
Capacity (HP): 400 HP

Quantity: 1
Type: CAT-3406

Quantity: 1
Capacity: 263 KVA

Diameter: N/A
Capactiy (HP): N/A

Equipment Specifications Evertson #4 – 750HP Drilling

LOCATION: Faja Region, Venezuela
RIG OWNER: Evertson International
RIG NAME: Evertson-04
YEAR BUILT / SERIAL NUMBER: 1997 -REBUILT IN 2016 / SN: 97012-5
CONDITION / STATUS: Available
RIG TYPE: Land (Drilling)

RIG CLASSIFICATION: Trailer-Mounted
CURRENT FIELD / OPERATOR:
DATE OF LAST OVERHAUL:  July 2016
DATE OF NEXT OVERHAUL: July 2021

Motor: MTU Series 2000

Capacity (HP): 750 HP
Transmission: Allison 6600
Diameter (inches): 1.125″
Brake Type: DISC

Model/Type: IRI 75′
Capacity (lbs): 300,000
Max Depth (feet): 8,000

Pressure (PSI): 3,000 PSI

Bore Diameter: 13-5/8″

Pressure (PSI): 5,000 PSI

Diameter (inches): 4″

Pipe Tong: (1) Hawk 950-H 2.875″ x 9.50″ (2,662 ft-lbs)

Casing Tong: Farr Model KT-13625 (35,000 ft-lbs)

Quantity: 1
Model: GD-PZ7
Type: Triplex
Capacity (HP): 550 HP

Quantity: 1
Model: GD-PZ8
Type: Triplex
Capacity (HP): 750 HP

Quantity: 1
Type: Detroit Diesel Series 60

Quantity: 1
Type: Caterpillar 3508

Quantity: 2
Capacity: 350 KVA; 235 KVA

Diameter: 17.5″
Capacity (HP): 400

Bowen s250TPA

Equipment Specifications Evertson #5 – 350HP Workover

LOCATION: Faja Region, Venezuela
RIG OWNER:
Evertson International
RIG NAME:
Evertson-05
YEAR BUILT / SERIAL NUMBER:
1970 -REBUILT IN 2016 / SN: TD6001
CONDITION / STATUS:
Under Contract/ Active
RIG TYPE:
Land (Workover)

RIG CLASSIFICATION: Self-Propelled
CURRENT FIELD / OPERATOR:
Junin Division / Petrocedeño
DATE OF LAST OVERHAUL:  October 2016
DATE OF NEXT OVERHAUL:
October 2021

Motor: Detroit Diesel Series 60

Capacity (HP): 350 HP
Transmission: Allison 4500 OFS
Diameter (inches): 0.875″
Brake Type: Hydraulic

Model/Type: Watson Hopper GXXTA 75′
Capacity (lbs): 100,000
Max Depth (feet): 7,000 with 3.5″ Tubing

Pressure (PSI): 3,000 PSI

Bore Diameter: 11″

Pressure (PSI): 5,000 PSI

Tubing Tong: (1) Clincher 5.5″ x 6.25″ (12000 ft-lbs)

Rod Tongs: (1) Hillman Kelley Model 500-C (4,500 ft-lbs); (1) Oil Country Model M50 (2,050 ft-lbs)

Quantity: 1
Model: GD TGH-A
Type: Triplex
Capacity (HP): 400 HP

Quantity: 1
Type: Detroit Diesel Series 60

Quantity: 2
Capacity: 150 KVA Each

Diameter: N/A
Capacity (HP): N/A

Equipment Specifications Evertson #7 – 550HP Workover

LOCATION: Faja Region, Venezuela
RIG OWNER:
Evertson International
RIG NAME:
Evertson-07
YEAR BUILT / SERIAL NUMBER:
 2014; S/N: 853
CONDITION / STATUS:
Available
RIG TYPE:
Land (Workover)

RIG CLASSIFICATION: Self-Propelled
CURRENT FIELD / OPERATOR:
N/A
DATE OF LAST OVERHAUL:  N/A
DATE OF NEXT OVERHAUL:
September 2020

Motor: Detroit Diesel Series 60

Capacity (HP): 550 HP
Transmission: Allison 4500 OFS
Diameter (inches): 11″
Brake Type: DISC

Model/Type: Service King 575 104′
Capacity (lbs): 250,000
Max Depth (feet): 10,000

Pressure (PSI): 3,000 PSI

Bore Diameter: 11″

Pressure (PSI): 5,000 PSI

Tubing Tong: (1) Clincher 5.5″ x 6.375″ (12,000 ft-lbs)

Rod Tongs: (1) Hillman Kelley Model 500-C (4,500 ft-lbs); (1) Oil Country Model M50 (2,050 ft-lbs)

Quantity: 1
Model: GD TGH-A
Type: Triplex
Capacity (HP): 400 HP

Quantity: 1
Type: Detroit Diesel Series 60

Quantity: 2
Capacity: 150 KVA Each

Diameter: N/A
Capacity (HP): N/A

Equipment Specifications Evertson #8 – 550HP Workover

LOCATION: Faja Region, Venezuela
RIG OWNER:
Evertson International
RIG NAME:
Evertson-08
YEAR BUILT / SERIAL NUMBER:
2015; S/N 938
CONDITION / STATUS:
Available
RIG TYPE:
Land (Workover)

RIG CLASSIFICATION: Self-Propelled
CURRENT FIELD / OPERATOR:

DATE OF LAST OVERHAUL: N/A
DATE OF NEXT OVERHAUL:
February 2022

Motor: Detroit Deisel Series 60

Capacity (HP): 550 HP
Transmission: Allison 4500 OFS
Diameter (inches): 11″
Brake Type: DISC

Model/Type: Service King 575 104′
Capacity (lbs): 250,000
Max Depth (feet): 10,000

Pressure (PSI): 3,000 PSI

Bore Diameter: 11″

Pressure (PSI): 5,000 PSI

Tubing Tong: (1) Clincher 5.5″ x 6.375″ (12,000 ft-lbs)

Rod Tongs: (1) Hillman Kelley Model 500-C (4,500 ft-lbs); (1) Oil Country Model M50 (2,050 ft-lbs)

Quantity: 1
Model: GD TGH-A
Type: Triplex
Capacity (HP): 400 HP

Quantity: 1
Type: Detroit Diesel Series 60

Quantity: 2
Capacity: 150 KVA Each

Diameter: N/A
Capacity (HP): N/A

Equipment Specifications Evertson #9 – 500HP Workover

LOCATION: Faja Region, Venezuela
RIG OWNER:
Evertson International
RIG NAME:
Evertson-09
YEAR BUILT / SERIAL NUMBER:
Rebuilt- 2018; S/N 366
CONDITION / STATUS:
Under Contract/ Active
RIG TYPE:
Land (Workover)

RIG CLASSIFICATION: Self-Propelled
CURRENT FIELD / OPERATOR:
Ayachucho Division/ Petropiar
DATE OF LAST OVERHAUL:
  January-2018
DATE OF NEXT OVERHAUL:
September- 2023

Motor: Detroit Diesel Series 60

Capacity (HP): 500 HP
Transmission: Allison 4500 OFS
Diameter (inches): 11″
Brake Type: Hydraulic

Model/Type: Watson Hopper GXXTA 102′
Capacity (lbs): 260,000
Max Depth (feet): 10,000

Pressure (PSI): 3,000 PSI

Bore Diameter: 11″

Pressure (PSI): 5,000 PSI

Tubing Tong: (1) Clincher 5.5″ x 6.375″ (12,000 ft-lbs)

Rod Tongs: (1) Hillman Kelley Model 500-C (4,500 ft-lbs); (1) Oil Country Model M50 (2.050 ft-lbs)

Quantity: 1
Model: GD TGH-A
Type: Triplex
Capacity (HP): 400 HP

Quantity: 1
Type: Detroit Diesel Series 60

Quantity: 2
Capacity: 150 KVA Each

Diameter: N/A
Capacity (HP): N/A

Equipment Specifications Evertson #10 – 500HP Workover

LOCATION: Faja Region, Venezuela
RIG OWNER:
Evertson International
RIG NAME:
Evertson-10
YEAR BUILT / SERIAL NUMBER:
Rebuilt in 2019 / SN 389
CONDITION / STATUS:
Under Contract/ Active
RIG TYPE:
Land (Workover)

RIG CLASSIFICATION: Self-Propelled
CURRENT FIELD / OPERATOR:
Ayacucho Division/ Petropiar
DATE OF LAST OVERHAUL:
February- 2019
DATE OF NEXT OVERHAUL:
February- 2024

Motor: Detroit Diesel Series 60

Capacity (HP): 500 HP
Transmission: Allison 6061
Diameter (inches): 11″
Brake Type: Hydraulic

Model/Type: Watson Hopper GXXTA 96′
Capacity (lbs): 220,000
Max Depth (feet): 10,000

Pressure (PSI): 3,000 PSI

Bore Diameter: 11′

Pressure (PSI): 5,000 PSI

Tubing Tong: (1) Clincher 5.5″ x 6.375″ (12,000 ft-lbs)

Rod Tongs: (1) Hillman Kelley Model 500-C (4,500 ft-lbs); (1) Oil Country Model M50 (2,050 ft-lbs)

Quantity: 1
Model: GD TGH-A
Type: Triplex
Capacity (HP): 400 HP

Quantity: 1
Type: Detroit Diesel Series 60

Quantity: 2
Capacity: 150 KVA Each

Diameter: N/A
Capacity (HP): N/A
